DTC 2-1

NOTE: The TCS control unit performs the self-diagnosis for the steering angle sensor when the average speed of the two rear wheels exceeds 10 mph (16 km/h). The TCS indicator light comes on if a yaw rate is generated and the steering angle signal that corresponds to this yaw rate is not inputted when the steering wheel is turned, while there is no input from the STOP (brake light signal) and PARK (parking brake signal).
