Home >> Acura >> 1992 >> Vigor L5-2451cc 2.5L SOHC G25A4 FI >> Repair and Diagnosis >> Engine, Cooling and Exhaust >> Cooling System >> Testing and Inspection >> System Does Not Operate at All

System Does Not Operate at All

Fig. 12 Electric Cooling Fan Diagnosis, System Does Not Work At All:
